Brand	AMD
Model	AMD Ryzen™ 7 5700
Product Code	100-000000743
Series	Ryzen 5000 Series
Processor Architecture	Zen 3
CPU Socket	AM4
PCI Express® Version	PCIe® 3.0
Total Cores	8
Total Threads	16
Multithreading (SMT)	Yes
Max. Boost Clock	Up to 4.6GHz
Base Clock	3.7GHz
L1 Cache	512KB
L2 Cache	4MB
L3 Cache	16MB
Graphics Model	Discrete Graphics Card Required
Max of Memory Channels	2
System Memory Subtype	UDIMM
System Memory Type	DDR4
Max Memory Speed	2x1R:DDR4-3200 // 2x2R: DDR4-3200 // 4x1R: DDR4-2933 // 4x2R: DDR54-2667
Supporting Chipsets	X570 , X470 , X370 , B550 , B450 , B350 , A520
Default TDP	65W
PPT	61-88W
Max Operating Temperature	95°C
Thermal Solution (PIB)	No
Unlocked for Overclocking	Yes
Processor Technology for CPU Cores	TSMC 7nm FinFET
Package Die Count	1
Native USB 3.2 Gen 2 (10Gbps)	4
Native PCIe® Lanes (Total/Usable)	24 , 20
Additional Usable PCIe Lanes from Motherboard	X570: 16x Gen 3 // X470: 2x Gen 3, 8x Gen 2
Supported Extensions	AES , AMD-V , AVX , AVX2 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Supported Technologies	AMD StoreMI Technology , AMD Ryzen™ VR-Ready Premium
OS Support	Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit , Windows 11 - 64-Bit Edition

AMD Ryzen 7 5700 – 8 Cores & 16 Threads, 4.6GHz, 20MB Cache, 3200 DDR4, PCIe 3.0, AM4, Tray
