Product Collection	14th Generation Intel® Core™ i5 Processors
Vertical Segment	Desktop
Processor Number	i5-14400F
Lithography	Intel 7
Total Cores	10
Performance-cores	6
Efficient-cores	4
Total Threads	16
Max Turbo Frequency	4.70 GHz
Performance-core Max Turbo Frequency	4.70 GHz
Efficient-core Max Turbo Frequency	3.50 GHz
Efficient-core Base Frequency	1.8 GHz
Performance-core Base Frequency	2.50 GHz
Cache	20 MB Intel® Smart Cache
Total L2 Cache	9.5 MB
Processor Base Power	65 W
Max Memory Size	192 GB
Maximum Turbo Power	148 W
Memory Types	Up to DDR5 4800 MT/s // Up to DDR4 3200 MT/s
Instruction Set Extensions	Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Use Conditions	PC/Client/Tablet
Max of Memory Channels	2
Max Memory Bandwidth	76.8 GB/s
Direct Media Interface (DMI) Revision	4
Max of DMI Lanes	8
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations	Up to 1x16+4, 2x8+4
Max of PCI Express Lanes	20
Sockets Supported	FCLGA1700
Max CPU Configuration	1
Thermal Solution Specification	PCG 2020C
Package Size	45.0 mm x 37.5 mm
Max Operating Temperature	100 °C
Intel® Turbo Boost Technology	2
Instruction Set	64-bit
Intel® Gaussian & Neural Accelerator	3
Intel® Thread Director	Yes
Embedded Options Available	No
Intel® Volume Management Device	Yes
Intel® Deep Learning Boost on CPU	Yes
Intel® Speed Shift Technology	Yes
Intel® Hyper-Threading Technology	Yes
Intel® 64	Yes
Idle States	Yes
Enhanced Intel SpeedStep® Technology	Yes
Thermal Monitoring Technologies	Yes
Intel® Standard Manageability (ISM)	Yes
Intel® Control-Flow Enforcement Technology	Yes
Intel® AES New Instructions	Yes
Secure Key	Yes
Intel® OS Guard	Yes
Execute Disable Bit	Yes
Intel® Boot Guard	Yes
Mode-based Execute Control (MBEC)	Yes
Intel® Virtualization Technology (VT-x)	Yes
Intel® Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® VT-x with Extended Page Tables (EPT)	Yes

Intel Core i5-14400F 10C 16T 2.5GHz 4.7GHz Turbo 20MB Cache DDR4 DDR5 PCIe 5.0 65W TDP Cooler Included
