Powerful 14th Gen Performance for Gaming, Streaming & Content Creation:

The Intel® Core™ i7-14700 14th Gen Desktop Processor (BX8071514700) delivers high-performance hybrid processing power for demanding PC builds. Featuring 20 cores (8 Performance-cores + 12 Efficient-cores) and 28 threads, the i7-14700 achieves maximum Max Turbo Frequency speeds up to 5.4 GHz. Built on the LGA 1700 socket with support for both DDR5 and DDR4 memory, this processor handles high-framerate AAA gaming, heavy video rendering, and multi-threaded creative workflows with ease.

Key Features:

Enhanced Hybrid Architecture: Combines 8 P-Cores for intense single-threaded gaming with 12 E-Cores to handle background applications and multi-tasking effortlessly.
Intel® Thread Director Optimization: Dynamically routes workloads to the correct cores in real-time, ensuring maximum efficiency under Windows 11.
Integrated Intel® UHD 770 Graphics: Features native integrated graphics for multi-monitor display outputs and Intel® Quick Sync Video encoding without requiring a discrete GPU immediately.
Flexible Memory Support: Offers backward compatibility with budget-friendly DDR4 RAM motherboards or full performance speed on modern DDR5 motherboards.
PCIe 5.0 & 4.0 Support: Provides up to 20 PCIe lanes for ultra-fast connection to next-gen PCIe 5.0 NVMe SSDs and high-end graphics cards.

specs:

Brand	Intel
Model	Intel® Core™ i7 processor 14700, 33M Cache, up to 5.40 GHz
Product Number	BX8071514700
Product Collection	Intel® Core™ i7 Processors (14th gen)
Processor Number	i7-14700
Total Cores	20
Performance-cores	8
Efficient-cores	12
Total Threads	28
Max Turbo Frequency	5.4 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency	5.4 GHz
Performance-core Max Turbo Frequency	5.3 GHz
Performance-core Base Frequency	2.1 GHz
Efficient-core Max Turbo Frequency	4.2 GHz
Efficient-core Base Frequency	1.5 GHz
Cache	33 MB Intel® Smart Cache
Total L2 Cache	28 MB
Processor Base Power	65 W
Maximum Turbo Power	219 W
Max Memory Size	192 GB
Memory Types	Up to DDR5 5600 MT/s // Up to DDR4 3200 MT/s
Max of Memory Channels	2
Max Memory Bandwidth	89.6 GB/s
ECC Memory Supported	Yes
GPU Name	Intel® UHD Graphics 770
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.6 GHz
Graphics Output	eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units	32
Max Resolution	HDMI: 4096 x 2160 @ 60Hz // DP: 7680 x 4320 @ 60Hz // eDP - Integrated Flat Panel: 5120 x 3200 @ 120Hz
*DirectX Support**	12
*OpenGL Support**	4.5
*OpenCL Support**	3.0
Direct Media Interface (DMI) Revision	4.0
Intel® Quick Sync Video	Yes
Displays Supported	4
Intel® Clear Video HD Technology	Yes
Max of DMI Lanes	8
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations	Up to 1x16+4, 2x8+4
Max of PCI Express Lanes	20
Sockets Supported	FCLGA1700
Thermal Solution Specification	PCG 2020C
Max Operating Temperature	100 °C
Intel® Turbo Boost Technology	2.0
Instruction Set	64-bit
Instruction Set Extensions	Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Package Size	45.0 mm x 37.5 mm
Intel® Gaussian & Neural Accelerator	3.0
Intel® Volume Management Device	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Max Technology 3.0	Yes
Intel® Hyper-Threading Technology	Yes
Intel® 64	Yes
Idle States	Yes
Enhanced Intel SpeedStep® Technology	Yes
Thermal Monitoring Technologies	Yes
Intel® Standard Manageability (ISM)	Yes
Intel® Control-Flow Enforcement Technology	Yes
Intel® AES New Instructions	Yes
Secure Key	Yes
Intel® OS Guard	Yes
Execute Disable Bit	Yes
Intel® Boot Guard	Yes
Mode-based Execute Control (MBEC)	Yes
Intel® Virtualization Technology (VT-x)	Yes
Intel® Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® VT-x with Extended Page Tables (EPT)	Yes
Resources	https://www.intel.com/content/www/us/en/products/sku/236781/intel-core-i7-processor-14700-33m-cache-up-to-5-40-ghz/specifications.html

Intel Core i7-14700 20 Cores, 28 Threads, Up to 5.4GHz, LGA 1700 Desktop Processor
